Ford F-150 2021-2024 Service & Repair Manual

Description

The complete factory service and repair manual for the 2021, 2022, 2023 and 2024 Ford F-150 — the same procedures a Ford dealer technician works from, delivered as a searchable PDF the moment you pay. It covers the fourteenth-generation truck end to end: 222 service sections with step-by-step procedures, wiring diagrams, specifications and torque figures across every system on the vehicle.

About the 2021–2024 F-150

The fourteenth-generation F-150 was Ford’s most ambitious redesign of America’s best-selling truck. It introduced the 3.5L PowerBoost — the first full-hybrid powertrain in an F-150 — along with Pro Power Onboard, the built-in generator that turns the truck into a mobile power source, and the SYNC 4 system, all on the aluminium-alloy body. It’s a genuinely complex truck, and that complexity is exactly why a complete factory service manual earns its place in the garage.

Vehicles covered

Ford F-150 (14th generation)
Model years: 2021, 2022, 2023, 2024

Engines documented

All six engine options:

• 2.7L EcoBoost V6 (twin-turbo)
• 3.3L Duratec V6
• 3.5L EcoBoost V6 (twin-turbo)
• 5.0L Ti-VCT V8
• 3.0L Power Stroke turbo-diesel V6
• 3.5L PowerBoost full-hybrid V6

Transmission & drivetrain

• 10-speed automatic transmission (10R80), including the hybrid MHT variant
• Rear-wheel drive and four-wheel drive, with transfer case
• Ford 8.8-inch and 9.75-inch rear axles

What’s inside

Engine and engine management, the 10-speed transmission and transfer case, driveline and axles, brakes with ABS and stability control, the electrical system with wiring diagrams, schematics and connector information, body and cab, suspension, steering, heating and air conditioning, restraints (airbags/SRS), emissions, and collision and body repair.

Common issues this manual helps you tackle

Every truck has its known trouble spots, and the 2021–2024 F-150 is no exception. This manual carries the full factory procedures for the systems behind the most-discussed ones:

• 10-speed automatic (10R80) shift quality — harsh or hesitant shifts and driveline vibration are the most common complaints on these trucks. The transmission section covers the 10R80 end to end — diagnosis, internal service and specifications — so you can separate a genuine fault from normal behaviour.
• Electric parking brake — the subject of the generation’s largest recall. The brake section documents the electric parking brake, its actuation, testing and service.
• Rear axle and differential — the Max-Duty axle bolts and pinion-seal leaks are well-known concerns. The driveline and axle sections cover both the 8.8-inch and 9.75-inch rear axles, including seals, bearings and torque specs.
• 2.7L EcoBoost intake valves and cam timing — early 2.7L trucks saw intake-valve and cam-phaser issues. The engine sections cover the valvetrain, timing and full teardown for each engine.
• PowerBoost hybrid and 12V electrical — the hybrid system and 12V battery drew early complaints. The manual documents the PowerBoost engine, its electric motor and powertrain cooling, plus the electrical, charging and module systems.

Whether you’re fixing it yourself, keeping a truck on the road out of warranty, or checking whether a shop’s diagnosis holds up, these are the factory procedures the dealer technicians use.

Format

Searchable PDF. Opens on Windows, Mac, Linux, tablets and phones. English. Instant download — your link is issued as soon as payment clears.

Frequently asked questions

Does it cover the PowerBoost hybrid?
Yes. The 3.5L PowerBoost is fully documented, including its MHT hybrid transmission.

Is the 3.0L diesel included?
Yes. The Power Stroke turbo-diesel is covered alongside the gas engines.

Can I search the manual?
Yes. Jump straight to any system, part or procedure.

Does it include wiring diagrams?
Yes. The electrical sections include full wiring diagrams, schematics and connector and pinout information for the charging system, batteries, modules and the CAN communication network.

What years does it fit?
Every model year from 2021 to 2024 — 2021, 2022, 2023 and 2024.
