Ford Explorer 2016-2019 Service & Repair Manual

Description

The complete factory service and repair manual for the 2016, 2017, 2018 and 2019 Ford Explorer — a 9,451-page workshop manual with integrated wiring diagrams across 163 factory service sections, plus the Powertrain Control and Emissions Diagnosis reference, delivered as an instant download.

About the 2016–2019 Explorer

These are the final four years of the fifth-generation Explorer, after the 2016 facelift brought the new nose and swapped the 2.0L EcoBoost for the 2.3L. It is the last front-drive-based Explorer — from 2020 Ford moved the whole vehicle onto a rear-drive platform — so this generation stands on its own mechanically, and a 2020 manual will not help you with one.

Vehicles covered

Ford Explorer (fifth generation, facelift), including Sport, Platinum and the Police Interceptor Utility
Model years: 2016, 2017, 2018, 2019

Engines documented

• 2.3L EcoBoost four-cylinder (turbocharged, direct injection)
• 3.5L Duratec Ti-VCT V6
• 3.5L EcoBoost V6 (twin-turbo — the Sport and Platinum engine)
• 3.7L Ti-VCT V6 (Police Interceptor Utility)

Transmission & drivetrain

• 6F35 six-speed automatic transaxle
• 6F50 and 6F55 six-speed automatic transaxles
• Front-wheel drive and all-wheel drive, with the power transfer unit and rear drive unit

What’s inside

163 factory sections covering engine mechanical and management for all four engines, the three transaxles, the all-wheel-drive system, brakes with anti-lock and stability control, steering and suspension, climate control, restraints, emissions, body and closures, and a genuinely deep electrical section — over a thousand wiring diagram references, more than five thousand pinpoint tests and 460 identified connectors. The Powertrain Control and Emissions Diagnosis volume is included for driveability and code work.

Common issues this manual helps you tackle

• Exhaust odour in the cabin — the best-known complaint on this generation, investigated at length by federal regulators and addressed by Ford through sealing and reprogramming work. The exhaust, body sealing and climate control sections document the components involved.
• Water pump failure on the V6 engines — the Cyclone V6 water pump is internal, driven by the timing chain, so a failed seal sends coolant into the crankcase rather than onto the driveway. The engine sections cover the pump, its drive and the cooling system it sits in.
• Six-speed shift quality and harsh engagement — a long-standing complaint on the 6F transaxles. The transmission sections carry valve body service, solenoid operation, adaptive relearn and full overhaul procedures.

Whether you are keeping a high-mileage Explorer honest or checking whether a shop’s diagnosis holds up, these are the procedures the dealer technicians work from.

Format

Searchable PDF. The main workshop manual with wiring runs to 9,451 pages, and the download also includes the PCED diagnosis volume and the vehicle’s reference documentation. Opens on Windows, Mac, Linux, tablets and phones. English. Instant download after checkout.

Frequently asked questions

Are wiring diagrams included?
Yes — wiring is integrated into the main workshop manual, with connector identification and thousands of pinpoint tests.

Does it cover the Police Interceptor Utility?
Yes. The 3.7L Ti-VCT V6 used in the Police Interceptor Utility is documented alongside the retail engines.

Will it fit a 2020 Explorer?
No. 2020 moved to a completely different rear-drive platform with ten-speed transmissions, so it needs the 2020–2022 manual.

Will it fit a 2013 Explorer?
Not properly. The 2016 facelift changed the engine line-up, so this manual is written for 2016 onward.

Which years does it fit?
2016, 2017, 2018 and 2019.
