Ford Mustang 2015-2017 Service & Repair Manual

Description

The complete factory service and repair manual for the 2015, 2016 and 2017 Ford Mustang — 9,517 searchable pages of dealer-level procedures, specifications, torque figures and electrical detail, delivered the moment you pay. This is the sixth-generation car in full: every engine, both transmissions, coupe and convertible.

About the 2015–2017 Mustang

The S550 was the biggest change to the Mustang in fifty years. The live rear axle finally gave way to an independent rear suspension, the 2.3L EcoBoost four brought turbocharged torque to the range, and for the first time the car was sold as a factory global product in right- and left-hand drive. The 3.7L V6 was still in the line-up through 2017 — and disappeared after it — which makes these three years a distinct, self-contained slice of Mustang history.

Vehicles covered

Ford Mustang (S550), fastback and convertible
Model years: 2015, 2016, 2017

Engines documented

• 2.3L EcoBoost four-cylinder (turbocharged, direct injection)
• 3.7L V6
• 5.0L V8 (GT)

Transmission & drivetrain

• MT82 six-speed manual transmission
• 6R80 six-speed automatic transmission
• Rear-wheel drive with independent rear suspension, driveshaft and rear axle service

What’s inside

Engine mechanical and engine management for all three engines, both transmissions and the clutch, driveline and rear axle, brakes with anti-lock and stability control, steering and the independent suspension, climate control, restraints, emissions, instrumentation and driver information, body and closures — including the convertible top — and the full electrical suite with schematics and connector and pinout information running throughout.

Common issues this manual helps you tackle

• Side door latch failure — 2015 cars were recalled when a latch spring tab could break, leaving a door that would not stay shut. The body and closures sections document latch removal, replacement and adjustment.
• 2.3L EcoBoost underbody heat — 2015 EcoBoost cars were recalled for heat damaging the fuel tank and vapour lines. The fuel system and exhaust sections cover the tank, its shielding and the vapour lines.
• MT82 manual shift quality — notchy shifts, gear clash and premature synchro wear are the best-known complaint on these cars. The manual transmission and clutch sections carry the internal service procedures and specifications.
• Highway-speed driveline vibration — a documented Ford diagnostic procedure built around driveshaft inspection and balancing. The driveline sections cover the driveshaft, its balancing and the rear axle.
• 2.3L turbocharger wastegate faults — a disconnected wastegate actuator rod causes underboost and a check-engine light on early EcoBoost cars. The engine and engine-management sections cover the turbocharger and its control.
• Driver door handle spring — 2017 cars were recalled for an interior handle spring that could unseat. The door hardware procedures are documented in full.

Format

Searchable PDF, 9,517 pages, no password or restrictions. Opens on Windows, Mac, Linux, tablets and phones. English. Instant download — your link is issued as soon as payment clears.

Frequently asked questions

Does it cover the EcoBoost and the GT?
Yes — the 2.3L EcoBoost, the 3.7L V6 and the 5.0L GT are all documented, with both the manual and automatic transmissions.

Is the convertible covered?
Yes. The body sections include the convertible top and its mechanism.

Does it include the Shelby GT350?
No. The GT350’s 5.2L flat-plane V8 is a separate model line and is not documented here — this manual covers the 2.3L, 3.7L and 5.0L cars.

Can I search it?
Yes — the whole manual is searchable text, so you can jump straight to a component, connector or torque figure.

Which years does it fit?
2015, 2016 and 2017 — the three years that share the 3.7L V6 and the six-speed transmissions, before the 2018 facelift moved to the ten-speed automatic.
